Capacity : 0 to 250 Kgf
(Each Dial shows Three Sub Ranges).

Gripping Device :
To test Fabric, Rubber, Wire, Rod, Strips and any other Specimen of various materials can be tested by interchangeable Gripping Jaws, which can be easily installed in the main gripping housing.

Drive and Traverse Speed :
The Drive of the Strength is affected by Three Phase Motor operating on 440 V.A.C. supply. The Machine is provided with Stepped (One Pulley) which can give various Speed Ranges.

Checking and Calibration :
The Calibration of the Machine is checked up with the Force Measuring Units which was tested and certified by National Physical Laboratory (NPL). The Machine is calibrated in Kgf.

Accuracy and Loading Ranges :
It is certified that the measuring error on any measuring ranges of this machine shall not be more than ±1% of the indicated load above the 1/5th of the scale value.

(Confirms to Requirements of Indian and International Standards).
